Advanced Packaging - Solutions for Power Electronics

F-Series

Soldering with Formic Acid and Vacuum within a flexible carrier & inline solution for flux-free preforms or solder pastes.

F-Serie FORMIC ACID

• offers the established reflow full convection system with vacuum function
• heat transfer is controlled energy-efficiently by individual regulating the fan speed
• enables a tool-free soldering process
• is modularly designed with 3 or 4 heating zones and 1-3 cooling zones
• can optionally be configured with up to three vacuum chambers in the process zones
• can be used flexibly for different products in the same process
• uses a general workpiece carrier that can be flexibly occupied
• has an intelligent safety concept in a closed system under a nitrogen atmosphere (less than 100 ppm residual oxygen content)
• uses an efficient evaporator process to save nitrogen and formic acid
• maintains a production cycle time of 90 – 105 s (standard DCBs).

F-Serie System Models

F-Series F3: 1 preheating zone, 2 x vacuum heating zones
F-Series F4: 1 preheating zone, 3 x vacuum heating zones

B-Series

A state-of-the-art reflow soldering system, designed for the production of extremely thin and light products with continuous negative pressure.

The new B-Serie

• guarantees “non-warping” of even the thinnest products from 0.2mm – 0.5mm thanks to an implemented Bernoulli effect and eliminates the curvature of the products
• offers three-lane, parallel transport with individually adjustable, coupled transport tracks for high throughput
• can be used flexibly for different products in the same process
• offers the established reflow full convection
• heat transfer can be permanently controlled by regulating the fan speed
• enables a tool-free soldering process
• brings energy saving potential with the intelligent “Profiling Plus” software application
• provides intelligent nitrogen control system
• guarantees reduced maintenance efforts
• has an optimized flux management system
• can be configured with up to 4 process gas cleaning units
• is equipped with the proven ABS cleaning system
• offers the option of individually setting the fans within the cooling zone
